The 6 axle dump trailer is designed to carry 80 tons or even over 100 tons of cargo, significantly increasing the single-trip transport capacity while meeting local axle load requirements.For transportation companies, the same number of drivers, fuel consumption, and transport time allow for the transport of more goods, effectively reducing the cost per ton of cargo and increasing operating profits.
The 6 axle structure distributes the weight of the semi dump trailers and cargo evenly across more axles, reducing the load on each axle. This not only improves the end dump trailer's stability under heavy loads but also reduces stress on tires, axles, leaf springs, and the frame, extending the overall vehicle's lifespan.
Overall dimension: 11000mm*2500mm*4000mm
Volume: 45CBM
Axles: 6 axles
Tire: 20 units, 11.00R20
Suspension: 2 air suspension + 4 mechanical suspension
Tipping system: end dump trailer
Landing gear: JOST E100
Brake system: WABCO
Electrical system: 24V, LED lights
The 6 axle dump trailer prices is not determined by a single factor, but is influenced by a variety of factors including vehicle configuration, raw materials, manufacturing process, brand, hydraulic system, and customer customization requirements.
One of the most important factors affecting end dump trailer prices is the steel used in the chassis and cargo box. The TITAN 6 axle dump trailer uses Q345B high strength steel. High strength steel has higher yield strength and better fatigue resistance, ensuring load bearing capacity while reducing the overall vehicle weight and improving transportation efficiency, thus resulting in a higher price.
Furthermore, steel plate thickness is also a significant factor affecting cost. For example, using 8mm wear-resistant steel plates for the floor and 6mm thicker side plates directly increases material costs but significantly extends the semi dump trailers' service life, making it particularly suitable for high wear conditions such as handling ores and rocks.
Axle, suspension system, and tire configuration are also important factors determining dump trailer prices. The TITAN 6 axle dump trailer is equipped with six heavy duty axles. Customers can choose 13 ton or 16 ton axles, and can also select mechanical suspension, air suspension, or front lift axle configurations according to transportation needs.
In addition, the vehicle's size and load capacity directly affect the end dump trailer prices. Different customers have different requirements for the length, width, height, and volume of the cargo box, with common cargo box volumes ranging from 40 cubic meters, 45 cubic meters to 50 cubic meters or even larger. The larger the cargo box, the more steel is required, and the overall vehicle reinforcement structure also needs to be upgraded accordingly, naturally increasing the semi dump trailer prices.
